    Jackery Explorer 500 Portable Power Station charges low to high-power appliances for long hours. With a high battery capacity of 518Wh, a foldable handle, an ergonomic design, and industry-leading BMS technology, the power station is ideal for outdoor adventurers and emergency home backup solutions. It is extremely easy to carry, with a weight of just 14.11 lbs.

    textRight

    High Battery Capacity

    Jackery Explorer 500 Portable Power Station features 1 * AC outlet, 2 * DC ports, 1 * car port, and 3 * USB-A ports to charge low to high-power appliances, including air pumps, CPAP machines, TV, mini-refrigerators and more. Its compact size and lightweight design make the power station ideal for road trips and RV camping.

    • Phone 18W

      29.4 Charges

    • TV 60W

      36H

    • Projection 5W

      220H

    • Desktop 200W

      10 H

    • Blender 300W

      7 H

    • Space Heater 350W

      1.5 H

    • Coffee Maker 550W

      0.8 H

    • Toaster 650W

      0.8 H

    • Ice Shaver 700W

      1.8 H

    More Appliance >
    Multiple Charging  Methods Available
    Multiple Charging  Methods Available
    Current Bundles Recharging Time
    (0-100%)
    Solar Charging
    9.5 H
    Wall Charging
    7.5 H
    Car Charging
    7.5 H
    With Jackery Explorer 500 Portable Power Station, you'll never have to worry about finding a wall outlet for recharging. Multiple other charging methods like solar panels, car outlets, or electric generators ensure you'll have the power to charge your gear anywhere, anytime.
     Long  Battery Life
    The best feature of the Jackery Explorer 500 Power Station is its long battery life. Even after completing 800 charge cycles, the power station will have 80% battery capacity.

    Clean and Green Solution

    2
    11
    Jackery Explorer 500 Portable Power Station does not emit fumes or use fuels, making it an eco-friendly and renewable power solution for camping, RV trips, off-grid living, and home backup.

    How to Connect Explorer 500 with SolarSaga 100?

    arrow
    PREPARING YOUR SOLAR GENERATOR

    The Explorer 500 can be fully charged under straight full sun in 9.5 hours by connecting SolarSaga 100W solar panel.

    Solar recharging steps:

    1. Find the DC interface on the back of SolarSaga 100;

    2. Connect the DC interface of SolarSaga 100 with DC input of Explorer 500

    Spec in Pictures

    arrow
    • 1 LED Flashlight
    • 2 DC Input
    • 3 DC Output
    • 4 Car Port
    • 5 USB Output
    • 6 AC Output
    • 7 LCD Screen
    Specs
    Jackery Explorer 500 Portable Power Station
    Battery
    Capacity: 518Wh
    Cell Chemistry: Lithium-ion
    Cycle life: 500 cycles to 80%+ capacity
    Management System: BMS, Over Voltage Protection, Short Circuit Protection
    Ports
    AC Output(x1): 230V, 50Hz, 500W (1.000W Peak)
    DC Output(x2): 12V⎓7A
    USB-A Output(x3): 5V⎓2,4A
    Car Port(x1): 12V⎓10A
    AC Input: doesn't support direct AC charging - use external AC charger provided
    DC Input: 24V⎓3,75A
    Dimensions
    Width: 7,6in(19,2cm)
    Height: 11,8in(30cm)
    Depth: 9,5in(24,2cm)
    Weight: 13,3lbs(6kg)
    Charging Time(0-100%)
    AC Adapter: 7,5 Hours
    Car Adapter(12V): 8 Hours
    Solar Panel: 1 x SolarSaga 60W Solar Panel: 7 Hours
    General
    Warranty: 2 Years
    Operating Usage Temperature: 14-104F (-10-40℃)
    Solar Panel Combination
    Solar Saga 80: Up to 1 pics
    Solar Saga 100: Up to 1 pics
    Solar Saga 200: Up to 1 pics

    What's in The Box

    arrow
    • 1 1* Explorer 500
    • 2 1* AC & AC Cable (2 Parts)
    • 3 1* Car Charger Cable
    • 4 1* User Manual (Explorer 500)
    Notes:
    1. Solar panel types and quantity depends on your purchase.
    2. Buy 2 SolarSoga, get 1*Solar Panel Connectors.
    3. Buy 4 or 6 SolarSoga, get 2*Solar Panel Connectors.

    User Manual

    arrow

    BATTERY INFO

    BATTERY INFO

    pdf
    Jackery Explorer 500 Portable Power Station User Manual.pdf
    icondown DOWNLOAD
    pdf
    Jackery Explorer 500 Portable Power Station User Manual.pdf
    icondown DOWNLOAD

    Notice

    arrow

    1. Solar panel types and quantity depends on your purchase.
    2. Buy 2 SolarSoga, get 1*Solar Panel Connectors.
    3. Buy 4 or 6 SolarSoga, get 2*Solar Panel Connectors.

    FAQ

    Q: What devices can Explorer 500 power?

    arrow
    A: Please note that the AC output port can only charge/power devices that operate at less than 500-Watt. Once exceeding, the Explorer 500 will shut off automatically. Please refer to your device specification before purchase.

    Q: How to know the working times for my device?

    arrow
    A: Working time = 500Wh* 0.85 / operating power of your device. For reference, assuming power consumption of your device is 60W (might be a box fan), working time will be 500Wh*0.85/60w=7hrs (rough calculated) . Please note: actual power consumption varies from different usages, please consult Jackery for better purchase decision.

    Q: How long does it take to full charge this power station?

    arrow
    A: Within 7.5 hours from an AC wall outlet; Also another two recharge backup choices for your convenience, recharge from car port around 7.5 hours, and around within 9.5 hours from Jackery Saga 100W solar panel (Sold Separately).
