Jackery SolarSaga 200W Solar Panel

    Mobile Menu Icon
    • FEATURES
    • TECH SPECS
    • FAQ
    • REVIEWS
    Jackery SolarSaga 200W Solar Panel features a high solar conversion efficiency of up to 24.3% - go green quickly. The ETFE-laminated case extends its lifespan, and the recommended angle ensures optimum absorption of the sunlight, making it the perfect power source for outdoor travel and home backup. It is portable, foldable, and can be hooked up instantly with a power station for the ideal solar power system.
    Featured Summary
    Easy to Use and Portable
    Foldable design for easy transport. It's also compact and lightweight for carrying on your outdoor activities. Simply fold the solar panel in two, in seconds and you'll be good to go, with convenient power at your fingertips in an instant.

    Built to Last

    2
    11
    The ETFE-laminated case ensures the solar panel is durable enough for a longer lifespan. Additionally, the IP67 Waterproof Rating allows it to withstand harsh and wet weather.
    Convenient Carrying
    A practical carrying bag is included for easy transport. Magnetic pads on the solar panel allow the solar panel to be folded up tightly and carried on your favourite off-grid journeys.
    Product Details

    Spec in Pictures

    arrow

    SolarSaga 200W

    Dimensions (unfolded): 53,34 x 235,46 x 2,49 cm

    SolarSaga 200W

    Dimensions (folded): 53,34 x 60,96 x 4,32 cm

    Specs
    Jackery SolarSaga 200W Solar Panel
    Ports
    USB-A Output: No
    USB-C Output: No
    Solar
    Peak Power: 200W
    Power Voltage: 18V
    Power Current: 11.12A
    Open Circuit Voltage: 23.2V
    Short Circuit Current: 11.76A
    Dimensions
    Folded: 21,2 x 24,2 x 1,6 in (540 x 615 x 40 mm)
    Unfolded: 21,2 x 91,3 x 1 in (540 x 2320 x 25 mm)
    Weight: 17.5±0.5lbs(8.0±0.3Kg)
    General
    Warranty: 1 Years
    Materiales: Monocrystalline Silicon Solar Cells
    Waterproof: IP67
    Efficiency rate: 24.30%
    Operating temperature: -10-65℃(14-149°F)
    In The Box
    1 x SolarSaga 200
    1 x 9.8inches DC Charging Cable
    1 x Carrying Bag
    1 x User Manual
    Portable Power Station
    Explorer 2000 Pro: Up to 6 pics
    Explorer 1500 Pro: Up to 6 pics
    Explorer 1000 Pro: Up to 4 pics
    Explorer 1000: Up to 2 pics
    Explorer 500: Up to 1 pics
    Explorer 240: Up to 1 pics

    User Manual

    arrow

    BATTERY INFO

    BATTERY INFO

    pdf
    Jackery SolarSaga 200W Solar Panel.pdf
    icondown DOWNLOAD
    pdf
    Jackery SolarSaga 200W Solar Panel.pdf
    icondown DOWNLOAD

    Notice

    arrow

    * This product (portable power supply) can supply power to your device in the temperature range of -10 to 40 degrees Celsius (-10 to 65 degrees Celsius for solar panels). If the operating temperature is outside the above range, this product may not work.

    FAQ

    Q: Why the solar can not produce 100W power when charging to Jackery power station?

    arrow
    As you know , the solar panels are affected by many factors. such as the intensity of the light and the angle of the panel put on the ground. 200W is tested in an ideal laboratory. However, the intensity of the light constantly changes. In addition, the angle of the light illuminating the solar panel also changes with the rotation of the sun. Please try test your solar panel under the full sunlight to see, and make sure there is no shadow cast on the panel.

    Q: Is the solar panel waterproof?

    arrow
    It is rated as IP67 water-resistant, offering protection against water splashes (Please avoid exposing it to heavy rain or submerging it in water). The pocket's zippers are designed to secure power cords and cover the power port.

    Q: How to clean the solar panel surface?

    arrow
    We mentioned this point in the manual. Please use a soft cloth to remove the dust and dirt on the surface. Use a damp cloth to wipe the surface of the solar module to remove any remaining dust or dirt. Any guano or other adhesive should be removed as soon as possible from the solar surface to avoid a reduction in performance.

    View More

    FAQ

    Q: Why the solar can not produce 100W power when charging to Jackery power station?

    arrow
    As you know , the solar panels are affected by many factors. such as the intensity of the light and the angle of the panel put on the ground. 200W is tested in an ideal laboratory. However, the intensity of the light constantly changes. In addition, the angle of the light illuminating the solar panel also changes with the rotation of the sun. Please try test your solar panel under the full sunlight to see, and make sure there is no shadow cast on the panel.

    Q: Is the solar panel waterproof?

    arrow
    It is rated as IP67 water-resistant, offering protection against water splashes (Please avoid exposing it to heavy rain or submerging it in water). The pocket's zippers are designed to secure power cords and cover the power port.

    Q: How to clean the solar panel surface?

    arrow
    We mentioned this point in the manual. Please use a soft cloth to remove the dust and dirt on the surface. Use a damp cloth to wipe the surface of the solar module to remove any remaining dust or dirt. Any guano or other adhesive should be removed as soon as possible from the solar surface to avoid a reduction in performance.

    View More
